MACHINE SPECIFICATIONS

OPERATIONS

Loader Arms: Radial
Operating Weight: 3393 kg
Rated Op Capacity @ 35%: 873 kg
Rated Op Capacity @ 50%: 1247 kg
Ground Pressure: 29.0 kPa / 4.2 psi
Engine Power: 50 kW / 67 hp
Tipping Load: 2495 kg
Max Travel Speed: 17.1 km/h

ENGINE

Features: Diesel 3-cylinder, Turbo Charged, After Cooled Deutz TCD 2.2 T4, Hydraulically Driven Fan, Dual Stage Intake Air Cleaner, Engine Block Heater.
Cooling System: Anti-Freeze Filled Radiator Cooling System.
Engine Power: 50 kW / 67 hp
Displacement: 2.2 L
Torque Peak: 250 Nm

DRIVE TRAIN

Features: Dual Hydraulic Drive Motors, 2 Independent Torsion Axle Suspension.
Roller Wheels: 24 High Density Polyurethane.
Front and Rear Wheels: 355.6 mm
Middle Wheels: 254 mm
Track Width: 381 mm
Length of Track on Ground: 1499 mm

DIMENSIONS

Full Length: 3594 mm
Arm Up Height: 2959 mm
Machine Height: 2068 mm
Machine Width: 1676 mm
Ground Clearance: 330 mm

AUXILIARY HYDRAULICS

Features: Pilot Hydraulic Joystick Control, Work Port Relief.
Max System Pressure: 22753 kPa
Couplers: Manual Quick Attach (Standard Models) or Hydraulic Quick Attach (Premium Model).
Auxiliary Pump Flow: 84.0 lpm (Standard Models) / 103.7 lpm (Premium Model)

ELECTRICAL SYSTEM

Features: Upgradeable Wiring Harness, Attachment Control Kit.
Normal Charge: 12 V
Battery: 800 CCA
Alternator Charging System: 120 Amp
Port Outlet (Inside Cab): 1 – 12 V

OPERATOR STATION

Features: Open or enclosed closed A/C cab optional. All include ROPS, Suspension Seat w/ 2 in. Seatbelt, Roof Panel, Rear Window, Sound Insulation, Horn, Backup Alarm, Lap Bar.
Loader Control: Right-hand pilot hydraulic joystick controls loader lift/tilt, with variable control of auxiliary hydraulics.
Drive Control: Left-hand pilot hydraulic joystick controls machine speed and direction.
Engine Speed: Electronic throttle.
Multifunction Display / Indicator: Fuel, Tachometer, Engine Temperature, Hour Meter, Battery, Trip Meter, Hydraulic Temperature, Water Temperature, Multiple Languages. Danfoss computer + AM/FM Radio in enclosed cab models.
Illumination: 2 Forward Facing Lights / 2 Rear Facing Lights.

SERVICE CAPACITY

Fuel Tank: 87.8 L
Hydraulic Tank: 12.5 L
Engine Coolant: 9.5 L
Engine Oil (inc Filter): 8 L
